Backup Systems

APC SMTL2200RM2UC. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1920 W. AC outlet types: NEMA 5–15R, NEMA 5–20R, AC outlets quantity: 8 AC outlet(s), Serial interface type: RJ-45. Battery technology: Lithium-Ion (Li-Ion), Typical backup time at full load: 6 min, Typical backup time at half load: 12 min. Form factor: Rackmount, Product color: Black, Silver, Rack capacity: 2U. Width: 17" (432.1 mm), Depth: 26.9" (683 mm), Height: 3.39" (86.1 mm)

APC Symmetra RM XR. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 2448 Ah, Battery voltage: 208 V. Form factor: 4U, Product color: Black. Weight: 242.5 lbs (110 kg). Dimensions (WxDxH): 19 x 25.2 x 7.01" (483 x 640 x 178 mm), Package dimensions (WxDxH): 23 x 32 x 13.5" (584 x 813 x 343 mm)

APC Smart-UPS VT. Output power capacity: 30 kVA, Input frequency: 60 Hz, Audible alarm modes: Battery replacement. Form factor: Tower, Product color: Black, Certification: UL 1778. Width: 13.8" (351 mm), Depth: 33" (837 mm), Height: 58.5" (1487 mm). Nominal output voltage: 208 V, Nominal input voltage: 480 V, Package dimensions (WxDxH): 28.5 x 43.5 x 65.5" (723 x 1104 x 1663 mm)

APC Smart-UPS 5000VA RM w/Transformer. Output power capacity: 5 kVA, Output power: 4000 W, Noise level: 53 dB. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 9.4 min, Typical backup time at half load: 26.7 min. Product color: Black, Cable length: 96.1" (2.44 m), Certification: CSA,FCC 15 A,UL 1778. Weight: 320.6 lbs (145.4 kg). Interface: DB-9 RS-232,RJ-45 10 Base-T ethernet / SNMP/ Telnet,SmartSlot, Output connections: (2) NEMA 5-15R . (12) NEMA 5-20R. (2) NEMA L6-20R. (1) NEMA L6-30R., Input connection type: NEMA L6-30P

APC SRT5KXLT. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 4250 W. AC outlet types: NEMA L6-20R, NEMA L6-30R, Power plug: NEMA L6-30P, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 1.50 h. Form factor: Compact, Product color: Black, Cable length: 120.1" (3.05 m). Width: 5.12" (130 mm), Depth: 28.3" (719 mm), Height: 17" (432 mm)

APC Smart-UPS RT 10,000VA 208V w/ (2) 208V to 120V Step-Down Transformer. Output power capacity: 10 kVA, Output power: 8000 W, Input frequency: 50/60 Hz. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 4.9 min, Typical backup time at half load: 14.8 min. Product color: Black, Certification: CSA,FCC Part 15 Class A,UL 1778. Weight: 495.2 lbs (224.6 kg). Interface: DB-9 RS-232, RJ-45 10/100 Base-T, Smart-Slot, Output connections: 16x NEMA 5-20R 2x NEMA L14-30R 6x NEMA L6-20R 3x NEMA L6-30R, Input connection type: 3-wire

APC SRT5KRMXLIM. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 4500 W. AC outlet types: C13 coupler, C19 coupler, IEC Jumpers, Power plug: Terminal, AC outlets quantity: 12 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 5 year(s), Battery recharge time: 1 h. Form factor: Mini Tower, Product color: Black, Display type: LCD. Width: 17" (432 mm), Depth: 28.3" (719 mm), Height: 5.12" (130 mm)

APC SMX3000RMLV2UNC. Output power capacity: 3 kVA, Output power: 2700 W, Input operation voltage (min): 75 V. AC outlet types: NEMA 5–15R, NEMA 5–20R, AC outlets quantity: 7 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product color: Black, Rack capacity: 2U. Width: 17" (432 mm), Depth: 26.3" (667 mm), Height: 3.35" (85 mm)

Vertiv Liebert GXT5-5000MVRT4UXLN. Output power capacity: 5 kVA, Output power: 5000 W, Waveform: Sine. Form factor: Rackmount/Tower, Product color: Black, Display type: LCD. Width: 16.9" (430 mm), Depth: 25.6" (650 mm), Height: 6.81" (173 mm)

Eaton Power-Sure 800. Output power capacity: 10 kVA, Output power: 10000 W, Efficiency: 92%. Form factor: Tower, Mean time between failures (MTBF): 200000 h, Safety: UL 1012, UL 544, cUL. Width: 20" (508 mm), Depth: 28.5" (723.9 mm), Height: 23" (584.2 mm)

APC SYMMETRA PX. UPS topology: Double-conversion (Online), Output power capacity: 10 kVA, Output power: 10000 W. Form factor: Rackmount, Product color: Black, Certification: cUL Listed, FCC Part 15 Class A, ISO 14001, ISO 9001, UL 60950, UL Listed. Width: 19" (483 mm), Depth: 27.6" (700 mm), Height: 5.2" (132 mm)

APC SRT2200RMXLI-NC. UPS topology: Double-conversion (Online), Output power capacity: 2.2 kVA, Output power: 1980 W. AC outlet types: C13 coupler, C19 coupler, AC outlets quantity: 12 AC outlet(s), Serial interface type: RJ-45. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 367 VAh, Battery life (max): 5 year(s). Form factor: Rackmount, Product color: Black, Rack capacity: 2U. Width: 17" (432 mm), Depth: 23" (584 mm), Height: 3.35" (85 mm)

Eaton 9PX6KSP. Output power capacity: 5.5 kVA, Output power: 4900 W, Input operation voltage (min): 176 V. AC outlet types: NEMA 5–20R, NEMA L14-30R, NEMA L6-30R, Terminal, Power plug: NEMA L14-30P, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA). Form factor: Rackmount/Tower, Product color: Black, Cable length: 70.9" (1.8 m). Width: 17.3" (440 mm), Depth: 25.6" (650 mm), Height: 6.8" (172.7 mm)

APC Smart-UPS X 2200VA. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1980 W. AC outlet types: C13 coupler, C19 coupler, C20 coupler, Power plug: C20 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 702 Ah, Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product color: Black, Rack capacity: 2U. Width: 7.01" (178 mm), Depth: 19" (483 mm), Height: 17" (432 mm)

Eaton 9170+. Output power capacity: 6 kVA, Output power: 5000 W, Input operation voltage (min): 176 V. AC outlet types: NEMA 5–20R, NEMA L14-30R, NEMA L6-30R, Power plug: Terminal, AC outlets quantity: 16 AC outlet(s). Battery recharge time: 4 h. Form factor: Rackmount/Tower, Product color: Black, Display type: LCD. Width: 16.9" (430 mm), Depth: 25.6" (650 mm), Height: 33.3" (845 mm)

APC Smart-UPS. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 2700 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 738 VAh, Typical backup time at full load: 6.25 min. Form factor: Rackmount/Tower, Product color: Black, Stainless steel, Rack capacity: 4U. Width: 7.01" (178 mm), Depth: 19" (483 mm), Height: 17" (432 mm)

Vertiv Liebert GXT5-6000IRT5UXLN. Output power capacity: 6 kVA, Output power: 6000 W

APC Symmetra RM 2kVA Scalable to 6kVA. Output power capacity: 2 kVA, Output power: 1400 W, Noise level: 60 dB. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 12.3 min, Typical backup time at half load: 28.4 min. Product color: Black, Cable length: 72" (1.83 m), Certification: CSA,FCC 15 A,UL 1778. Weight: 259.5 lbs (117.7 kg). Interface: DB-9 RS-232,RJ-45 10 Base-T ethernet / SNMP/ Telnet,SmartSlot, Output connections: (12) NEMA 5-20R (2) NEMA L6-20R , Input connection type: Hard Wire 3-wire (2PH + G) / NEMA L6-30P (30A Twist-Lock)
